TECHNICAL DESCRIPTION

EBIKEPORT STANDARD AC

FRAMEWORK

1.1SET OF MECHANO-WELDED HOT-GALVANIZED FITTINGS WITH BOLTINGS.

1.2 LC DOUGLAS FRAME EXCLUDING SAPWOOD WITH JOINTS FOR POSTS, PLATES, BEAMS, BEAMS AND FURRINGS.

1.3 BM SPRUCE FRAME WITH ASSEMBLIES FOR WALLS AND Rafters.

WOOD FRAME

BM SPRUCE UPRIGHTS 45X95MM ASSEMBLED IN WORKSHOP FOR LOAD-LOADING WOODEN FRAME.

BRACED IN 13MM OSB3 PARTICLE BOARDS

ASSEMBLY OF 45X95 MM WOODEN WALLS ON THE LC STRUCTURE



CLADDING (EXTERIOR FACE)

MAJCOAT 150 RAIN SHIELD FILM FOR FIRM CLADDING.

VERTICAL BATTLE BM SPRUCE 29X45MM.

HORIZONTAL BATTLE BM SPRUCE 29X45MM.

INSECT AND RODENT PROTECTION GRIDS FOR THE BOTTOM AND TOP OF EXTERIOR WALLS.

DOUGLAS VERTICAL CLADDING 28X90 + CLASS 3 GRAY TREATMENT



INTERIOR CLADDING AND CEILING

BM SPRUCE FRAME WITH ASSEMBLIES FOR LOODWOODS FOR HANGING REMOVABLE COVERING PANELS.

3-PLY SPICE PANELS 27 MM THICKNESS FOR REMOVABLE COVERING PANELS (WALLS).

DOUGLAS VERTICAL CLADDING 28X90MM + CLASS 3 GRAY TREATMENT FOR REMOVABLE COVERING PANELS.

CEILING IN 3-PLY SPICE PANELS 19MM THICKNESS WITH GROOVED FOR ROOFING IMITATION.

STEEL BAR ROOF OR SUN ROOF BAR BIO-COMPOSITE SYSTEM RECYCLED PLASTIC AND SAWDUST

PHOTOVOLTAIC PANELS: 370WC

GEL BATTERIES: 2 V AH 968 C 120

INVERTER CHARGER: 12V/24V/48V 70 A PV MAXIMUM 3000 W IN 48 V

ARUBA WIFI TERMINAL

55-INCH SCREEN WITH SHIELDED GLASS AND STAINLESS STEEL STRUCTURE

WISENET 4-CHANNEL RECORDER 3TB HARD DISK

360 AND 180 CAMERAS

4 OR 5 G MODEM-ROUTER

DEFIBRILLATOR WITH THERMO-REGULATED AND TRACEABILITY BOX

STRUCTURAL DIMENSION

LENGTH: 5500

WIDTH: 2620

TOTAL STEEL TRAY ROOF WIDTH: 3020

STRUCTURE HEIGHT AT LOWEST: 2245

STRUCTURE HEIGHT AT THE HIGHEST: 2500

TOTAL HEIGHT AT LOWEST: 2405

TOTAL HEIGHT AT THE HIGHEST: 2660
